CMSC 210: Lecture 13

Lecture 13: HTML & CSS, Part II

CSS

Announcements

Assignment 3 is due Tomorrow, March 16.
No late assignments.


        <!doctype html>
        <html lang="en">
          <head>
            <title>Hello, world!</title>
          </head>
          <body>
            <h1>Hello, world!</h1>
            <p>Here is a very small and simple document.</p>
            <h2>Links I like:</h2>
            <ul>
                <li><a href="http://google.com/">Google</a></li>
                <li><a href="http://amazon.com/">Amazon</a></li>
                <li><a href="http://netflix.com">Netflix</a></li>
            </ul>
          </body>
        </html>

And remember the document object model (DOM) representation as a tree?

Browsers expose two ways for web
developers to do things with the DOM

JavaScript: interaction & dynamically modifying the HTML tree
Cascading Style Sheets (CSS): styling elements in the HTML tree

CSS

Not a programming language; a "stylesheet language"
Initial release of CSS circa 1996 (the web is already approx. 5 years old at this point)
Wasn't widely supported by browsers till early 2000s
Wasn't correctly supported by many browsers for years after that
CSS support among browsers has gotten pretty good in the last 10 years or so.

Designed to allow separation of content from presentation

HTML → adding semantic meaning to a text document

CSS → adding presentational information to an HTML document

What do we mean by styling?

Typography
Color
Layout
Spacing & positioning
Borders
inline vs. block

Consider <h1>: it's for indicating the most important heading. "Important" doesn't imply anything about color, typeface, size, etc.

You could do this...


    <h1>
        <font size="16" face="Times" color="red">Big Headline</font>
    </h1>

But it's extremely limited.

And not a good idea.

Context & Presentation May Vary

...but content stays the same.

Separating presentation info into its own CSS file also makes the HTML far less cluttered and allows for far more control over how things look with less code.

How does CSS work?

write a rule that matches some part of the DOM tree
specify attributes that style the matched nodes
Style is applied to the matched nodes and all their children
More specific rules always override less specific ones
Source of rule also determines precedence...
(...that's the cascading part)

RULE: Text in unordered lists should be green!

RULE: The last <li> in a list should be orange.

What a CSS rule looks like


            <selector> {
                <property-1>: <value-1>;
                <property-2>: <value-2>;
            }

Universal selector


            * {
                color: green;
            }

Element selector


            li {
                color: green;
            }

Grouping selectors


        li, h2, p {
            color: green;
        }

Selecting descendants


        ul li {
            color: green;
        }

Selecting children


        li > a {
            color: green;
        }

Pseudo classes


        a:hover, li:last-child {
            color: green;
        }

Is there a way I can designate
elements in my HTML for styling?

YES!

The id attribute is used to specify a unique identifier for a single HTML element


        <a href="email:gl26499@umbc.edu" id="email-link">email me!</a>

The class attribute is used to specify a class or grouping for one or more HTML elements


        <p class="important" >Here's some important text!</p>
        <p>Here's some regular tex</p>
        <p class="important" >And more important text!</p>

id is meant for targeting a single element
class is meant for targeting multiple elements

Remember: HTML is intended to add semantic meaning to documents, so try to choose you names accordingly.

Good class names: important, logo, warning, signup-button
Bad class names: abc123, redText, paragraph, bold

ID selectors


        button#login {
            background-color: #c10547
        }

(#c10547 is a hexadecimal color code for magenta)

class selectors


        .pagination {
            width: 500px;
        }

Units of measurement should generally be in pixels (px). There are others, but they are more complex to work with.

What if you need to arbitrarily
group some elements together?

Use a <div> (probably with a class name or id)

What if you need to arbitrarily
style some text selection?


        <h3>What if you need to <span class="important">arbitrarily
        style</span> some text selection?</h3>

Remember this ugly thing?

Let's make it look nicer...

View the HTML and CSS here.

There are two ways two include CSS in an HTML document that browsers will understand.

Embed directly in the document's <head> section:


<style>
    h1 {
        color: #fefefe;
    }
    p, ul, ol {
        font-face: Helvetica;
    }
</style>

Link a file in the document's <head> section:


        <link rel="stylesheet" href="style.css">
